Check Settings under the System Setup Screens
Use the C-more 6” Micro-Graphic panel’s System Setup Screens to check the various settings
such as the LCD contrast, background color, beep and orientation. See Chapter 5: System
Setup Screens for additional details.
LCD Contrast - Used to adjust the LCD display’s contrast. The default is a value of 8, and the
range is 1 to 16, with 16 being the highest contrast. Adjust as necessary.
Beep - Used to enable or disable the internal audible beeper. the default is beep on.
Calibration - Used to calibrate the touch screen on the panel.
Cleaning the Display Screen
The display screen should be cleaned periodically by wiping it with a lint free damp cloth using
a mild soap solution. Dry the surface when finished with a lint free cloth. Do not use cleaning
solvents (ammonia, alcohol, acetone, etc.) which may damage the plastic housing and touch
screen.
The longevity of the touch screen can be increased by the use of a EA-6-COV2 clear screen
overlay. See Chapter 3: Accessories for additional information on the screen overlay.
To prevent damage to the touch screen, avoid touching the screen with sharp objects, striking
the screen with a hard object, using abrasives on the screen, or using excessive force when
pressing the touch screen.
7–5
Chapter 7: Maintenance
7
EA1-MG6-USER-M Hardware User Manual, 1st Ed. Rev C, 09/10
