C-more micro EA1-S6ML User Manual

2–6
Chapter 2: Specifications
2
®
EA1-MG6-USER-M Hardware User Manual, 1st Ed. Rev C, 09/10
Communications Ports
NOTE: The panel has one built-in RJ12 serial communications port (Port1 - RS-232) and one 15-pin serial
communications port (Port2 - RS-232/422/485). Only one of the ports can be used with a connected PLC.
The programming software allows the user to select either Comm. Port1 or Comm. Port2 under the Panel
Manager dialog box. When using Port2 to communicate with the connected PLC, Port1 can still be used with
the EA-MG-PGM-CBL Software Programming Cable Assembly to transfer projects between the PC and panel.
IS ED
IS ED
7M17
7M17
Date code:****
Date code:****
5432 1
R01
R01
MADE IN CHINA
MADE IN CHINA
EA1-S6MLW + ser al number
EA1-S6MLW + ser al number
MODEL:EA1 S6MLW
MODEL:EA1 S6MLW
INPUT:12-24V 6.5W
INPUT:12-24V 6.5W
IND CONTEQ.
IND CONTEQ.
6 5 4 3 2 1
Pin Signal
1 Logic GND
not used
RXD (232C)
TXD (232C)
2
3
4
5 +5 VDC
RJ12 serial
communications Port1
6 Logic GND
81
15
9
Pin Signal
1 Frame GND
TXD (232C)
RXD (232C)
Future
2
3
4
5 Logic GND
Pin Signal Pin Signal
6LE
CTS (232C)
RTS (232C)
RXD+ (422/485)
7
8
9
10 RXD (422/485)
11 TXD+ (422/485)
TXD (422/485)
Term Resistor
do not use
12
13
14
15 do not use
PLC 15-pin serial
communications Port2
RS-232 RS-232/422/485
Expansion
Connector
