Omron Host Link Protocol – PLC Error Code Table
The following table lists the errors that can be generated by the Omron PLC when using the
Host Link protocol.
Note: The following errors can be generated from the designated PLC, are monitored by the C-more Micro-
Graphic panel, and displayed on the panel’s screen as a hexadecimal value in panel error code P499, if active.
Please refer to the PLC manufacturer’s documentation for additional information.
PLC Error Codes for Omron Host Link
Panel Error Code
P499 Hex Value
Description
0x00 Normal Completion.
0x01 Not executable in RUN mode.
0x02 Not executable in MONITOR mode.
0x03 Not executable with PROM mounted.
0x04 Address over (data overflow).
0x0B Not executable in PROGRAM mode.
0x0C Not executable in DEBUG mode.
0x0D Not executable in LOCAL mode.
0x10 Parity error.
0x11 Framing error.
0x12 Overrun.
0x13 FCS error.
0x14 Format error (parameter length error).
0x15 Entry number data error (parameter error, data code error, data length error).
0x16 Instruction not found.
0x18 Frame length error.
0x19 Not executable (due to Un-executable error clear, non-registration of I/O table, etc.).
0x20
I/O table generation impossible (unrecognized remote I/O unit, channel over, duplication of optical
transmitting I/O unit).
0xA0 Abort due to parity error in transmit data under process.
0xA1 Abort due to framing error in transmit data under process.
0xA2 Abort due to overrun in transmit data under process.
0xA3 Abort due to FCS error in transmit data under process.
0xA4 Abort due to format error in transmit data under process.
0xA5 Abort due to frame length error in transmit data under process.
0xA8 Abort due to entry number data error in transmit data under process.
0xB0 Un-executable due to program area capacity other than 16k bytes.
