USB to RS232 Programming Cable Assembly (cont’d)
USB to RS232 Converter Specifications
Part Number:
EA-MG-PGM-CBL
Description:
6-ft. cable assembly to connect personal computer to any
C-more
Micro-Graphic panel for
setup and programming. (Note: This cable assembly uses the PC's USB port and converts the
signals to serial transmissions. The USB port supplies 5 VDC to the
C-more
Micro-Graphic
panel for low-power mode configuration operations.) Assembly includes standard USB A-
type connector to B-type connector cable, custom converter, and an RS232C cable with RJ12
modular connector on each end.
Hardware:
• USB Interface
USB Specification Rev. 1.1
Connector: USB Type B jack to accept USB Type B cable plug
• Serial Interface
RS232 (EIA-232-E)
Connector: RJ12 phone jack 6p to accept RJ12 cable plug
• Baud Rate
115.2 kbps Maximum
• Input Voltage
5 VDC (Supplied thru serial interface cable.)
• Power Consumption
50 mA (Does not include power to panel and/or bezel.)
Accessory Cables:
• USB Cable
USB Type A plug to PC on one end, USB Type B plug to converter on other end,
0.30 m [1 foot] length (* Note)
• Serial Cable
RJ12 phone plug connectors on both ends, 2.0 m [6.56 feet] length (* Note)
Environmental:
• Operating Temperature
0 to 50 °C (32 to 122 °F)
• Storage Temperature
-20 to 60 °C (-4 to 140 °F)
• Humidity
5 to 95 % RH (non-condensing)
• Environmental air
No corrosive gases permitted
• Vibration
IEC60068-2-6 (Test Fc), 5-9 Hz: 3.5 mm amplitude, 9-150 Hz: 1.0G, sweeping, at a rate of
1 octave/min. (±10%), 10 sweep cycles per axis on each of 3 mutually perpendicular axes
• Shock
IEC60068-2-27 (Test Ea), 15 G peak, 11 ms duration, three shocks in each direction
per axis, on 3 mutually perpendicular axes (total of 18 shocks)
Physical:
• Dimensions
2.559” (W) x 1.417” (H) x 0.886” (D)
[65.0 mm x 36.0 mm x 22.5 mm]
• Weight
1.06 oz. [30 g]
* Note: Maximum cable length for either the USB or serial cable should not exceed 2.0 m [6.56 feet] in length.
