Canon XF605 User Manual

Video Scopes
100
Options for [Type]
[Line]: Sets the waveform monitor to line display mode.
[Line+Spot]: The waveform of the area in the red frame is displayed in red on top of the [Line] mode
waveform.
[Select Line]: The selected horizontal line (in red) will be displayed along with its waveform.
[RGB]: Shows 3 side-by-side waveforms in an RGB parade.
[YPbPr]: Shows 3 side-by-side waveforms in a YPbPr parade.
Options for [Vertical Scale for HDR]
[IRE]: Displays the video scope in IRE units.
[PQ/HLG]: For HDR-PQ images, displays the video scope in nits (cd/m
2
) and the narrow range’s (video
range) waveform monitor.
For HDR-HLG images, the Y axis shows a relative-index value between 0.0 and 1.0.
NOTES
NOTES
• If the waveform monitor is activated and the > [/ Custom Picture] > [Edit / File] > [Knee] > [Point]
setting is changed, when you display the waveform monitor, a horizontal line will appear indicating the
luminance (Y) level* corresponding to the knee point.
* When a Look File registered to the custom picture file is active, the displayed luminance may not be at the correct level.
• When the waveform monitor’s Y axis is set to display in IRE units, a level of 10 bit 64 maps to 0 IRE and 10 bit
940 maps to 100 IRE, regardless of the custom picture settings.
Changing the Vectorscope Settings
1 Select > [ A Assistance Functions] > [Vectorscope Settings] > [Type] > Desired option.
2 Select > [
A Assistance Functions] > [Vectorscope Settings] > [Gain] > [1x] or [2x].
Options for [Type]
[Normal]: Displays the usual vectorscope.
[Spot]: The color signal of the area in the red frame is displayed in red on top of the [Normal] mode
waveform.
