Recording Video and Photos
Onscreen Displays
Refer to this section for an explanation of the various screen displays that appear in CAMERA mode. You can
use the custom display function (A 191) to turn off individual onscreen displays if they are not required. The
menu item that controls each display is given in the following tables (1: indicates a menu item under [Custom
Display 1] and 2: indicates a menu item under [Custom Display 2]).
The position of some icons and onscreen displays may change depending on the display level settings, which
can be set to level 1, level 2 or level 3. The following screenshot and tables describe the onscreen displays at
display level 1 with the [All Displays] setting (A 46).
AF frames
You can turn AF frames on/off with the > [
¢ Monitoring Setup] > [Custom Display 1] > [Focus Mode]
setting.
Continuous AF frame – in white
when [AF Frame] is set to either
[Large] or [Small] (A 77)
AF-Boosted MF frame – in yellow:
manual adjustment range; in white:
automatic adjustment range; in red:
nearer focus is not possible. (A 76)
Face AF: Main subject (A 78)
Face AF:
Only one face detected or faces
other than the main subject
Tracking: Subject selection (A 80)
Tracking: During tracking
Eye detection: Main subject's
eyes (A 78)
Frame shown when focus adjustments
are not possible: in red. You cannot
focus nearer when [AF Mode] is set to
[Continuous] and [AF Frame] is set to
[Whole Area].
Focus guide frame

Canon XF605 Specifications

General

Sensor type	CMOS
Total megapixels	13.4 MP
Optical sensor size	1/1 \
Filter size	58 mm
Optical zoom	15 x
Image stabilizer	Yes
Image stabilizer type	Optical Image Stabilization (OIS)
Maximum aperture number	2.8
Focal length (35mm film equivalent)	25.5 - 382.5 mm
3D	No
Camcorder type	Handheld camcorder
Image processor	DIGIC DV 7
Remotely operated	-
Minimum illumination	1.5 lx
Focus adjustment	Auto/Manual
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	- GB
Product color	Black
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum frame rate	120 fps
Video formats supported	H.265, MP4, MPEG4, MXF
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Image formats supported	JPEG
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Display diagonal	3.5 \
Viewfinder type	Optical
PCM digital audio	16-bit/48 kHz
Camera shutter speed	1/2000 s
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Storage temperature (T-T)	-5 - 45 °C
Operating temperature (T-T)	0 - 40 °C
ISO sensitivity	200, 12800, Auto
Battery capacity	- mAh
Battery life (max)	2.5 h
Video recording time	- h
Number of diaphragm blades	9

Weight and Dimensions

Depth	173 mm
Width	168 mm
Height	333 mm
Weight	2010 g
