Synchronizing with an External Device
• When a suitable external time code signal is received, the camera’s own time code will be synchronized to it
and the synchronization will be maintained even if you disconnect the cable from the TIME CODE terminal.
• If the external time code signal is incorrect or there is no input signal, the internal time code set in the camera
will be recorded instead.
• When an external time code signal is received, the DF/NDF selection will follow the external time code signal’s
settings.
• If an external time code signal is input while pre-recording is activated, there might be a discontinuity in the
time code of the pre-recorded clip.
• Performing any of the following actions while the cable is not connected will cause the synchronization to be
disrupted; the correct time code will be restored once you reconnect the cable.
- Turning the camera on/off
- Switching to MEDIA mode
- Changing the video configuration
Time Code Signal Output
The time code signal output from the TIME CODE terminal will be a SMPTE-standard LTC timing signal. The user
bit will also be output.
Select > [B System Setup] > [TC In/Out] > [Out].
NOTES
NOTES
• About the user bit output: The user bit set by the user (A 87) will be output. In MEDIA mode, the user bit is not
output from the TIME CODE terminal.
• The time code and user bit will not be output when slow & fast motion recording, frame recording or interval
recording are activated.
Reference Video Signal Input (Genlock Synchronization)
When a reference sync signal (analog blackburst or tri-level signal) is input through the G-LOCK/SYNC terminal,
the phases of the camera's V and H sync will automatically be synchronized to it. The phase difference between
the external Genlock signal and the camera is initially set to 0. The H phase can be adjusted within the range of
approximately ±0.4 H.
1 Select > [B System Setup] > [G-LOCK/SYNC Term.] > [Genlock Input].
2 Select > [B System Setup] > [Genlock Adjustment] > [Change].
• To reset the adjustment value to [000], select [Reset] instead.
3 Enter the H-phase adjustment value using the data entry screen (A 27).
NOTES
NOTES
• When a suitable Genlock signal is input, the Genlock synchronization stabilizes after approximately
10 seconds.
• When a suitable Genlock signal is detected, the U icon will flash at the top right of the screen. When the
camera locks on the external Genlock signal, the icon will stay on.
• If the external Genlock signal is incorrect, the synchronization may not be stable. In such case, the recorded
time code may be incorrect.

Canon XF605 Specifications

General

Sensor type	CMOS
Total megapixels	13.4 MP
Optical sensor size	1/1 \
Filter size	58 mm
Optical zoom	15 x
Image stabilizer	Yes
Image stabilizer type	Optical Image Stabilization (OIS)
Maximum aperture number	2.8
Focal length (35mm film equivalent)	25.5 - 382.5 mm
3D	No
Camcorder type	Handheld camcorder
Image processor	DIGIC DV 7
Remotely operated	-
Minimum illumination	1.5 lx
Focus adjustment	Auto/Manual
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	- GB
Product color	Black
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum frame rate	120 fps
Video formats supported	H.265, MP4, MPEG4, MXF
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Image formats supported	JPEG
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Display diagonal	3.5 \
Viewfinder type	Optical
PCM digital audio	16-bit/48 kHz
Camera shutter speed	1/2000 s
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Storage temperature (T-T)	-5 - 45 °C
Operating temperature (T-T)	0 - 40 °C
ISO sensitivity	200, 12800, Auto
Battery capacity	- mAh
Battery life (max)	2.5 h
Video recording time	- h
Number of diaphragm blades	9

Weight and Dimensions

Depth	173 mm
Width	168 mm
Height	333 mm
Weight	2010 g
