Canon XF605 User Manual

109
Special Recording Modes
• About the time code when interval recording is activated:
- The time code mode can be set to [Regen.], or to [Preset] with [Rec Run] running mode. The time code
advances by the number of frames recorded every time.
- If the time code running mode was set to [Free Run] or the camera was synchronized to an external time
code signal, the time code running mode will be changed automatically to [Rec Run] when interval recording
is activated.
- When the special recording mode is deactivated, the time code running mode will return to its previous
setting.
- The time code signal will not be output from the TIME CODE terminal, SDI OUT terminal or HDMI OUT
terminal.
Continuous Recording
Audio and video are recorded on both cards in this mode, normal recording on SD card A, and continuous
recording on SD card B. This function can be used when the main recording format is set to MP4. Video will be
recorded in MP4 format and audio will be recorded in linear PCM format.
With the exception of step 5, you can also use direct touch control to perform this function (A 49).
1Insert an SD card into each card slot (slot A for normal recording, slot B for continuous recording).
2 Select > [Æ Recording/Media Setup] > [Recording Mode] > [ Main / Continuous Rec].
• The continuous recording mode is activated and [CONT] appears on the screen next to the SD card B
indicator.
3 Select > [Æ Recording/Media Setup] > [Continuous Recording] > [REC].
• The tally lamp changes from green (power indicator) to red and continuous recording starts on SD card B.
The onscreen display changes to [ÜCONT].
4Press the REC button to start recording.
• Normal recording on SD card A starts.
• If you press the button before step 3, recording will start on both cards.
5 Select > [Æ Recording/Media Setup] > [Continuous Recording] > [STBY].
• The tally lamp goes out and recording stops on both cards. The onscreen display changes to [CONT].
6 Select > [Æ Recording/Media Setup] > [Recording Mode] > [Normal Recording] to turn off
continuous recording.
NOTES
NOTES
• When continuous recording is activated, if recording on SD card B (continuous recording) is not available,
normal recording on SD card A will not be possible either.
• Continuous recording will continue even if SD card A becomes full.
• If [Continuous Recording] is set to [STBY] and the main recording format is changed to an option other than
MP4, continuous recording will be canceled.

Canon XF605 Specifications

General

Sensor type	CMOS
Total megapixels	13.4 MP
Optical sensor size	1/1 \
Filter size	58 mm
Optical zoom	15 x
Image stabilizer	Yes
Image stabilizer type	Optical Image Stabilization (OIS)
Maximum aperture number	2.8
Focal length (35mm film equivalent)	25.5 - 382.5 mm
3D	No
Camcorder type	Handheld camcorder
Image processor	DIGIC DV 7
Remotely operated	-
Minimum illumination	1.5 lx
Focus adjustment	Auto/Manual
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	- GB
Product color	Black
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum frame rate	120 fps
Video formats supported	H.265, MP4, MPEG4, MXF
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Image formats supported	JPEG
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Display diagonal	3.5 \
Viewfinder type	Optical
PCM digital audio	16-bit/48 kHz
Camera shutter speed	1/2000 s
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Storage temperature (T-T)	-5 - 45 °C
Operating temperature (T-T)	0 - 40 °C
ISO sensitivity	200, 12800, Auto
Battery capacity	- mAh
Battery life (max)	2.5 h
Video recording time	- h
Number of diaphragm blades	9

Weight and Dimensions

Depth	173 mm
Width	168 mm
Height	333 mm
Weight	2010 g
