Canon XF605 User Manual

77
Focus
Continuous AF
The camera will focus automatically on a subject inside the main area of the image (approximately 80% of the
screen’s length and height).
1 Set the focus mode switch to automatic.
• @ appears on the screen.
2 Select > [ v Camera Setup] > [AF Mode] > [Continuous].
• If [AF Frame] is set to either [Large] or [Small], a white AF frame will appear on the screen.
• When you are using Face AF, a white detection frame will appear around the face of the person who has
been determined to be the main subject.
3 If necessary, change the type and position of the AF frame (A 78).
NOTES
NOTES
About the autofocus (AF) functions:
• The point where the camera focuses may change slightly depending on shooting conditions, such as subject,
brightness and zoom position. Check the focus before resuming shooting.
• Autofocus may take longer in the following cases.
- When the frame rate set in the video configuration is 29.97P, 25.00P or 23.98P.
• You can change various aspects of the autofocus function with the following settings.
- > [ v Camera Setup] > [AF Speed] to set the AF speed (the speed at which the focus is adjusted)
to one of 3 levels.
- > [ v Camera Setup] > [AF Response] to set the responsiveness of the autofocus function to one
of 3 levels.
• The autofocus settings cannot be used in the following cases.
- When > [v Camera Setup] > [Digital Zoom] is set to [Tele-converter 6.0x] or [Tele-converter 3.0x].
- When > [v Camera Setup] > [Conversion Lens] is set to either [TL-U58] or [WA-U58].
- When the [Gamma] setting in the custom picture file (A 123) is set to [PQ] or [HLG].
- When infrared recording is activated.
• Autofocus may not work well on the following subjects or in the following cases. In such case, focus manually.
- When using small apertures.
- When subjects at different distances appear in the picture.
- When the gamma curve component of the [Gamma/Color Space] setting in the custom picture file (A 123)
is set to an option other than [BT.709 Normal] or [BT.709 Standard].
- Reflective surfaces
- Subjects with low contrast or without vertical lines
- Fast moving subjects
- Through dirty or wet windows
-Night scenes
- Subjects with a repetitive pattern

Canon XF605 Specifications

General

Sensor type	CMOS
Total megapixels	13.4 MP
Optical sensor size	1/1 \
Filter size	58 mm
Optical zoom	15 x
Image stabilizer	Yes
Image stabilizer type	Optical Image Stabilization (OIS)
Maximum aperture number	2.8
Focal length (35mm film equivalent)	25.5 - 382.5 mm
3D	No
Camcorder type	Handheld camcorder
Image processor	DIGIC DV 7
Remotely operated	-
Minimum illumination	1.5 lx
Focus adjustment	Auto/Manual
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	- GB
Product color	Black
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum frame rate	120 fps
Video formats supported	H.265, MP4, MPEG4, MXF
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Image formats supported	JPEG
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Display diagonal	3.5 \
Viewfinder type	Optical
PCM digital audio	16-bit/48 kHz
Camera shutter speed	1/2000 s
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Storage temperature (T-T)	-5 - 45 °C
Operating temperature (T-T)	0 - 40 °C
ISO sensitivity	200, 12800, Auto
Battery capacity	- mAh
Battery life (max)	2.5 h
Video recording time	- h
Number of diaphragm blades	9

Weight and Dimensions

Depth	173 mm
Width	168 mm
Height	333 mm
Weight	2010 g
