Recording Audio
Recording Audio
The camera features the following options for audio recording and playback. You can record audio using an
external microphone/line-in device (INPUT terminal / MIC terminal), or the built-in microphone.
The audio signal will be output with the video signal from the SDI OUT terminal or HDMI OUT terminal. You can
record the audio signal on an external recorder.
Available audio recording formats
* Audio for proxy clips is recorded in AAC format.
Audio Settings and Recorded Audio Channels
Video format / audio recording
function
Audio format
Codec
Sampling
frequency
Bit depth
Number of
audio channels
Bit rate
Video
recording
XF-AVC Linear PCM
48 kHz
24 bit 4 channels 4.5 Mbps
MP4*
Linear PCM 16 bit 4 channels 3 Mbps
AAC 16 bit 2 channels 256 Kbps
Audio
recording
For slow & fast motion recording – 48 kHz 24 bit 4 channels 4.5 Mbps
For second card recording
functions
– 8 kHz 16 bit 1 channel 128 Kbps
Menu settings Recorded audio channels/audio sources
[Audio Input Selection]
1
[CH2 Input]
1
CH1 CH2 CH3 CH4
[CH1/CH2] [CH3/CH4]
[INPUT Terminals]
[INPUT
Terminals]
2
[INPUT 2] INPUT 1 terminal INPUT 2 terminal INPUT 1 terminal INPUT 2 terminal
[INPUT Terminals]
[INPUT
Terminals]
2
[INPUT 1] INPUT 1 terminal INPUT 1 terminal INPUT 1 terminal INPUT 2 terminal
[INPUT Terminals] [MIC Terminal] [INPUT 2] INPUT 1 terminal INPUT 2 terminal MIC terminal (L) MIC terminal (R)
[INPUT Terminals] [MIC Terminal] [INPUT 1] INPUT 1 terminal INPUT 1 terminal MIC terminal (L) MIC terminal (R)
[INPUT Terminals] [Built-in Mic] [INPUT 2] INPUT 1 terminal INPUT 2 terminal
Built-in microphone
(L)
Built-in microphone
(R)
[INPUT Terminals] [Built-in Mic] [INPUT 1] INPUT 1 terminal INPUT 1 terminal
Built-in microphone
(L)
Built-in microphone
(R)
[INPUT Terminals]
[Multi-Function
Shoe]
3
[INPUT 2] INPUT 1 terminal INPUT 2 terminal
Audio terminal
(commercially
available accessory)
Audio terminal
(commercially
available accessory)
[INPUT Terminals]
[Multi-Function
Shoe]
3
[INPUT 1] INPUT 1 terminal INPUT 1 terminal
Audio terminal
(commercially
available accessory)
Audio terminal
(commercially
available accessory)
[MIC Terminal]
[INPUT
Terminals]
2
– MIC terminal (L) MIC terminal (R) INPUT 1 terminal INPUT 2 terminal
[MIC Terminal] [MIC Terminal] – MIC terminal (L) MIC terminal (R) MIC terminal (L) MIC terminal (R)
[MIC Terminal] [Built-in Mic] – MIC terminal (L) MIC terminal (R)
Built-in microphone
(L)
Built-in microphone
(R)
[MIC Terminal]
[Multi-Function
Shoe]
3
– MIC terminal (L) MIC terminal (R)
Audio terminal
(commercially
available accessory)
Audio terminal
(commercially
available accessory)
[Built-in Mic]
[INPUT
Terminals]
2
–
Built-in microphone
(L)
Built-in microphone
(R)
INPUT 1 terminal INPUT 2 terminal
[Built-in Mic] [MIC Terminal] –
Built-in microphone
(L)
Built-in microphone
(R)
MIC terminal (L) MIC terminal (R)

Canon XF605 Specifications

General

Sensor type	CMOS
Total megapixels	13.4 MP
Optical sensor size	1/1 \
Filter size	58 mm
Optical zoom	15 x
Image stabilizer	Yes
Image stabilizer type	Optical Image Stabilization (OIS)
Maximum aperture number	2.8
Focal length (35mm film equivalent)	25.5 - 382.5 mm
3D	No
Camcorder type	Handheld camcorder
Image processor	DIGIC DV 7
Remotely operated	-
Minimum illumination	1.5 lx
Focus adjustment	Auto/Manual
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	- GB
Product color	Black
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum frame rate	120 fps
Video formats supported	H.265, MP4, MPEG4, MXF
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Image formats supported	JPEG
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Display diagonal	3.5 \
Viewfinder type	Optical
PCM digital audio	16-bit/48 kHz
Camera shutter speed	1/2000 s
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Storage temperature (T-T)	-5 - 45 °C
Operating temperature (T-T)	0 - 40 °C
ISO sensitivity	200, 12800, Auto
Battery capacity	- mAh
Battery life (max)	2.5 h
Video recording time	- h
Number of diaphragm blades	9

Weight and Dimensions

Depth	173 mm
Width	168 mm
Height	333 mm
Weight	2010 g
