Canon XF605 User Manual

81
Image Stabilization
Image Stabilization
You can use the image stabilizer to compensate for camera shake and achieve steadier shots. Select an IS
mode that best fits your needs. When you are stationary and zooming in on far subjects using high zoom ratios,
it is possible to compensate for a high degree of camera shake by using Powered IS.
Dynamic IS Ä: Dynamic IS compensates for a higher degree of camera shake, such as when shooting while
walking, and is more effective as the zoom approaches full wide angle.
Standard IS Å: Standard IS compensates for a lower degree of camera shake, such as when shooting while
remaining stationary, and is suitable for shooting natural-looking scenes.
Powered IS È: Powered IS is most effective when you are stationary and zooming in on far subjects using
high zoom ratios (the more you approach the telephoto end). This mode is not suitable for tilting and panning
shots.
1 Select > [ v Camera Setup] > [IS Mode] > Desired option.
• Press the button assigned to [IS Mode] to turn switch between IS modes (A 115).
2 Select > [ v Camera Setup] > [Image Stabilizer] > [On].
•The Ä or Å icon appears on the screen.
• Select [Off] instead to turn off the image stabilization, for example, when recording with the camera mounted
on a tripod.
• If you set an assignable button to [Image Stabilizer] (A 115), you can press the button to turn this setting
on/off.
3 If a higher level of image stabilization is required,
press the POWERED IS button.
• È appears on the left of the screen.
• Press the button again to return the camera to the IS
mode set in the menu.
• Alternatively, you can also use the >
[v Camera Setup]
> [Powered IS] setting to turn
Powered IS on and off.
NOTES
NOTES
• If the degree of camera shake is too high, the image
stabilizer may not be able to compensate fully.
• When using Dynamic IS, the edges of the picture may be adversely affected (ghosting, artifacts and/or dark
areas may appear) when compensating for a high degree of camcorder shake.
• The screen will turn black momentarily when you switch between Dynamic IS and Standard IS or vice versa.
• You cannot switch between Dynamic IS and Standard IS while recording.
• When using Dynamic IS, the angle of view will be narrower.

Canon XF605 Specifications

General

Sensor type	CMOS
Total megapixels	13.4 MP
Optical sensor size	1/1 \
Filter size	58 mm
Optical zoom	15 x
Image stabilizer	Yes
Image stabilizer type	Optical Image Stabilization (OIS)
Maximum aperture number	2.8
Focal length (35mm film equivalent)	25.5 - 382.5 mm
3D	No
Camcorder type	Handheld camcorder
Image processor	DIGIC DV 7
Remotely operated	-
Minimum illumination	1.5 lx
Focus adjustment	Auto/Manual
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	- GB
Product color	Black
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum frame rate	120 fps
Video formats supported	H.265, MP4, MPEG4, MXF
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Image formats supported	JPEG
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Display diagonal	3.5 \
Viewfinder type	Optical
PCM digital audio	16-bit/48 kHz
Camera shutter speed	1/2000 s
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Storage temperature (T-T)	-5 - 45 °C
Operating temperature (T-T)	0 - 40 °C
ISO sensitivity	200, 12800, Auto
Battery capacity	- mAh
Battery life (max)	2.5 h
Video recording time	- h
Number of diaphragm blades	9

Weight and Dimensions

Depth	173 mm
Width	168 mm
Height	333 mm
Weight	2010 g
