Preparing Recording Media
32
Inserting and Removing an SD Card
1 Wait until the SD CARD access indicator is off or is
illuminated in green.
2 Open the card compartment cover.
3Insert the card straight, with the label facing the side
of the operation buttons, into the SD card slot until it
clicks.
• You can use two cards, one in each card slot.
• To remove the card, make sure the SD CARD indicator
is off and then push the card once to release it. When
the card springs out, pull it all the way out.
4 Close the card compartment cover.
• Do not force the cover closed if the card is not correctly
inserted.
SD card access indicator
If you set > [
B System Setup] > [SD Card Access LED] to [Off], the SD card access indicator will not
illuminate.
IMPORTANT
• SD cards have front and back sides that are not interchangeable. Inserting a card facing the wrong direction
can cause a malfunction of the camera. Be sure to insert the card as shown in the illustration.
Initializing Cards
Initialize cards when you use them with this camera for the first time. You can also initialize a card to permanently
delete all the recordings it contains.
1 Select > [Æ Recording/Media Setup] > [Initialize Media].
2 Select the desired card.
3 Select [OK].
• The card is initialized and all the data it contains is erased.
IMPORTANT
• SD cards are initialized using the FAT file system, SDHC cards using the FAT32 file system, and SDXC cards
using the exFAT file system.
• Initializing a card will permanently erase all data, including photos and protected custom picture files. Lost data
cannot be recovered. Make sure you save important recordings in advance.
• Depending on the card, initialization may take up to a few minutes.
Indicator Card status
Red Accessing the card.
Green Recording/playback is possible and the card is selected for recording/playback.
Off A card is not inserted or the card slot is not currently selected.
햳
햵
햴
SD CARD indicator

Canon XF605 Specifications

General

Sensor type	CMOS
Total megapixels	13.4 MP
Optical sensor size	1/1 \
Filter size	58 mm
Optical zoom	15 x
Image stabilizer	Yes
Image stabilizer type	Optical Image Stabilization (OIS)
Maximum aperture number	2.8
Focal length (35mm film equivalent)	25.5 - 382.5 mm
3D	No
Camcorder type	Handheld camcorder
Image processor	DIGIC DV 7
Remotely operated	-
Minimum illumination	1.5 lx
Focus adjustment	Auto/Manual
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	- GB
Product color	Black
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum frame rate	120 fps
Video formats supported	H.265, MP4, MPEG4, MXF
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Image formats supported	JPEG
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Display diagonal	3.5 \
Viewfinder type	Optical
PCM digital audio	16-bit/48 kHz
Camera shutter speed	1/2000 s
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Storage temperature (T-T)	-5 - 45 °C
Operating temperature (T-T)	0 - 40 °C
ISO sensitivity	200, 12800, Auto
Battery capacity	- mAh
Battery life (max)	2.5 h
Video recording time	- h
Number of diaphragm blades	9

Weight and Dimensions

Depth	173 mm
Width	168 mm
Height	333 mm
Weight	2010 g
