Canon XF605 User Manual

Adjusting Camera and Recording Settings
50
Changing Camera Settings
1 Touch the setting you want to adjust, then select the desired value/
setting.
• Once the settings menu is displayed, touch to select the desired
value/setting as needed.
• When the slider appears, drag the slider left/right or touch the /
 buttons to adjust the desired value.
2Touch K.
Using Assistance Functions
1Touch A (assistance functions) and then turn assistance functions
on/off, or select the desired assistance function.
2Touch K.
Changing Recording Settings
1Touch Æ (Recording Settings)
• The recording settings menu will be displayed. There are three
pages that can be switched by swiping left and right.
2 Select the desired menu setting and then select the desired option.
3Touch X.
Direct Setting Mode (FUNC Button)
You can adjust main camera functions—white balance, aperture, ISO
speed/gain and shutter speed—using the FUNC button (direct setting
mode). This section will explain the basic operation of the direct setting
mode. For details about each function, refer to the respective section on
the manual.
1Press the FUNC button.
• The onscreen display of the selected function will be highlighted in
orange.
• Press the FUNC button repeatedly or push the joystick left/right to
select a different function.
2Push the joystick up/down to select the desired value or white
balance mode.
3Press SET.
• The selected value/mode will be set and direct setting mode will end.
• The onscreen display of the selected function will return to normal.
NOTES
NOTES
• The camera will automatically end the direct setting mode in the following cases.
- If no operation was performed for more than 6 seconds.
- If the FUNC button is pressed while selecting the shutter speed.
- If the menu or a status screen was opened.
Drag the slider to select the desired value

Canon XF605 Specifications

General

Sensor type	CMOS
Total megapixels	13.4 MP
Optical sensor size	1/1 \
Filter size	58 mm
Optical zoom	15 x
Image stabilizer	Yes
Image stabilizer type	Optical Image Stabilization (OIS)
Maximum aperture number	2.8
Focal length (35mm film equivalent)	25.5 - 382.5 mm
3D	No
Camcorder type	Handheld camcorder
Image processor	DIGIC DV 7
Remotely operated	-
Minimum illumination	1.5 lx
Focus adjustment	Auto/Manual
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	- GB
Product color	Black
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum frame rate	120 fps
Video formats supported	H.265, MP4, MPEG4, MXF
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Image formats supported	JPEG
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Display diagonal	3.5 \
Viewfinder type	Optical
PCM digital audio	16-bit/48 kHz
Camera shutter speed	1/2000 s
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Storage temperature (T-T)	-5 - 45 °C
Operating temperature (T-T)	0 - 40 °C
ISO sensitivity	200, 12800, Auto
Battery capacity	- mAh
Battery life (max)	2.5 h
Video recording time	- h
Number of diaphragm blades	9

Weight and Dimensions

Depth	173 mm
Width	168 mm
Height	333 mm
Weight	2010 g
