Focus
80
Tracking a Specific Subject
You can have the camera track other moving subjects that are not faces and also combine the tracking function
with one of the autofocus functions to let the camera focus on the desired subject automatically.
When [AF Mode] is set to [Continuous] and [AF Frame] is set to [Whole Area]
Touch the desired subject on the LCD screen.
• A double frame £ (tracking frame) is displayed and the camera will start tracking the selected subject.
• Press the CANCEL button to remove the frame and cancel the tracking.
• If tracking fails, will be displayed. Select the desired subject again.
When [AF Frame] is set to [Whole Area], [Large] or [Small]
1 Set an assignable button to [Tracking] (A 115).
2 Press the assignable button.
• The subject selection mark I will appear on the screen.
• Press the assignable button again or the CANCEL button to end the subject selection mode.
3 Touch the desired subject on the LCD screen.
•The
I mark changes to a double frame £ (tracking frame) and the camera will start tracking the selected
subject.
• You can also use the joystick (4 directions) to place the center of the
I mark on the desired subject and
then press SET.
• If the tracking failed, the
I mark will turn red momentarily. Select the subject again.
• The subject selected for tracking becomes the target for autofocus functions.
4 Press SET or the button assigned to [Tracking].
• The camera stops tracking and returns to subject selection mode.
• Press the CANCEL button to end the tracking function and return the camera to the focus mode that was
used previously.
NOTES
NOTES
• The camera may start tracking the incorrect subject if there is another subject in the picture with similar color/
pattern characteristics. In that case, select the desired subject again.
• Tracking cannot be used in the same cases in which face detection AF and eye detection cannot be used
(A 79).
Focus Limit and Macro Shooting
By default, the camera’s focus range allows macro shooting. You can activate the focus limit to restrict the focus
range. The focus range (1 cm (0.39 in.; at full wide-angle) to ) will be limited to 60 cm (2 ft.) to (throughout
the entire zoom range).
Select > [ v Camera Setup] > [Focus Limit] > [On].

Canon XF605 Specifications

General

Sensor type	CMOS
Total megapixels	13.4 MP
Optical sensor size	1/1 \
Filter size	58 mm
Optical zoom	15 x
Image stabilizer	Yes
Image stabilizer type	Optical Image Stabilization (OIS)
Maximum aperture number	2.8
Focal length (35mm film equivalent)	25.5 - 382.5 mm
3D	No
Camcorder type	Handheld camcorder
Image processor	DIGIC DV 7
Remotely operated	-
Minimum illumination	1.5 lx
Focus adjustment	Auto/Manual
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	- GB
Product color	Black
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum frame rate	120 fps
Video formats supported	H.265, MP4, MPEG4, MXF
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Image formats supported	JPEG
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Display diagonal	3.5 \
Viewfinder type	Optical
PCM digital audio	16-bit/48 kHz
Camera shutter speed	1/2000 s
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Storage temperature (T-T)	-5 - 45 °C
Operating temperature (T-T)	0 - 40 °C
ISO sensitivity	200, 12800, Auto
Battery capacity	- mAh
Battery life (max)	2.5 h
Video recording time	- h
Number of diaphragm blades	9

Weight and Dimensions

Depth	173 mm
Width	168 mm
Height	333 mm
Weight	2010 g
