Canon XF605 User Manual

59
ISO Speed/Gain
ISO Speed/Gain
You may want to adjust the brightness of the image according to the shooting conditions. You can choose
between manual and automatic settings. The camera offers 3 gain levels (L/M/H) that you can select simply by
changing the position of the ISO/GAIN switch. By choosing manual settings you can change the ISO speed or
gain value to adjust the sensitivity of the sensor.
You can also perform this function remotely using Browser Remote on a connected network device (A 177,
181).
Available ISO speed and gain settings
1
> [ Æ Recording/Media Setup] > [Main Rec Format] setting.
2
> [ v Camera Setup] > [ISO/Gain] setting.
3
Available values will depend on the gamma curve component of the [Gamma/Color space] setting in the custom picture file.
[Wide DR] or [Canon Log 3]: ISO 500 to ISO 12800 (-2.0 dB to 21.0 dB).
[PQ] or [HLG]: ISO 320 to ISO 12800 (-6.0 dB to 21.0 dB).
[BT.709 Normal] or [BT.709 Standard]: ISO 200 to ISO 12800 (-6.0 dB to 21.0 dB).
4
Only when using the [Gain Boost] setting (A 116).
Automatic ISO Speed/Gain
The sensitivity is automatically adjusted according to the
subject. You can also set a sensitivity limit.
Set the AGC switch to ON.
• The camera will adjust the gain automatically to obtain an
appropriate exposure.
• The gain value set automatically by the camera will appear
at the bottom of the screen with an icon next to it.
• The sensitivity limit is ISO 500 (-2.0 dB) when the [Gamma/
Color Space] setting in the custom picture file is set to
[Wide DR] or [Canon Log 3], ISO 320 (-6.0 dB) when set to
[PQ] or [HLG], and ISO 200 (-6.0 dB) when set to [BT.709 Normal] or [BT.709 Standard]
Setting an automatic ISO limit
By setting an ISO limit in automatic mode, you can curb the amount of noise and keep a dark ambient. When the
camera is set to full auto mode (A 42) or infrared recording is activated (A 110), the limit will be set to [Off/
21.0 dB] (when > [
v Camera Setup] > [ISO/Gain] is set to [ISO]) or [Off/ISO 12800] (when set to [Gain]).
Select > [v Camera Setup] > [Limit for Auto Mode] > Desired option.
Main recording
format
1
ISO/Gain
2
Increment Normal range
3
XF-AVC
MP4
[ISO]
[1 stop] 200, 400, 800, 1600, 3200, 6400, 12800
[1/3 stop]
200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600,
2000, 2500, 3200, 4000, 5000, 6400, 8000, 10000, 12800
[Gain]
[Normal] (3 dB)
-6.0 dB to 21.0 dB, 36.0 dB
4
[Fine] (0.5 dB)

Canon XF605 Specifications

General

Sensor type	CMOS
Total megapixels	13.4 MP
Optical sensor size	1/1 \
Filter size	58 mm
Optical zoom	15 x
Image stabilizer	Yes
Image stabilizer type	Optical Image Stabilization (OIS)
Maximum aperture number	2.8
Focal length (35mm film equivalent)	25.5 - 382.5 mm
3D	No
Camcorder type	Handheld camcorder
Image processor	DIGIC DV 7
Remotely operated	-
Minimum illumination	1.5 lx
Focus adjustment	Auto/Manual
Memory slots	2
Camcorder media type	Memory card
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	- GB
Product color	Black
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum frame rate	120 fps
Video formats supported	H.265, MP4, MPEG4, MXF
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Image formats supported	JPEG
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Display diagonal	3.5 \
Viewfinder type	Optical
PCM digital audio	16-bit/48 kHz
Camera shutter speed	1/2000 s
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Storage temperature (T-T)	-5 - 45 °C
Operating temperature (T-T)	0 - 40 °C
ISO sensitivity	200, 12800, Auto
Battery capacity	- mAh
Battery life (max)	2.5 h
Video recording time	- h
Number of diaphragm blades	9

Weight and Dimensions

Depth	173 mm
Width	168 mm
Height	333 mm
Weight	2010 g
