Preparing the Camera
28
Preparing the Camera
This section details how to prepare the camera for the first time, including how to attach the microphone holder
and the lens hood, as well as how to adjust the viewfinder.
Attaching the Microphone Holder
To the Right Side of the Handle Unit
1 Attach the microphone holder to the handle unit.
2 Use a commercially available Phillips head (“crosshead”) screwdriver
to secure it firmly with the 2 M4 bolts.
Attaching the Lens Hood
Attach the lens hood to protect the lens and reduce the amount of
stray light that may hit the lens. Additionally, keeping the lens
barrier closed can help avoid fingerprints and dirt on the lens.
Always remove the lens hood and attach the lens cap when
carrying the camera or storing it after use.
1 Remove the lens cap.
• The lens cap and lens hood cannot be used at the same
time.
2 Place the lens hood on the front of the lens with the lock
screw side pointing down
(햲) and turn it 90 degrees
clockwise
(햳).
• Be careful not to deform the lens hood.
• Make sure that the lens hood is aligned with the thread.
3 Tighten the lock screw (햴).
To Next Page
