6 . SPECIFICATIONS
6.10
Challenger MT500B EU
6.19 - CAPACITIES
6.20 - TIGHTENING TORQUES
6.20.1 - Wheels
6.20.2 - Miscellaneous
Type Model Capacity
Fuel tank MT535B / MT545B 270 l
MT555B / MT565B / MT575B 380 l
Cooling system 28.5 l
Engine sump MT525B / MT535B / MT545B 14.5 l
MT555B / MT565B / MT575B 20 l
Auxiliary hydraulics 100 l
Transmission hydraulics MT525B / MT535B / MT545B 56 l
MT555B / MT565B / MT575B 58 l
Rear final drive units (per side) MT525B / MT535B ND 5 l
MT525B HD* / MT535B HD /
MT545B
10 l
MT555B / MT565B / MT575B 13 l
Fixed front axle / Final drive units (per side) MT525B / MT535B ND* 6 l / 0.7 l
MT525B HD / MT535B HD / MT545B
/ MT555B / MT565B / MT575B
6 l / 1.5 l
Suspended front axle / Final drive units (per side) MT525B ND 8.5 l / 0.6 l
MT535B ND 8.5 l / 0.7 l
MT525B HD / MT535B HD / MT545B
/ MT555B / MT565B
8.5 l / 1.3 l
MT575B 8.5 l / 1.6 l
ND: “Normal Duty” normal assembly / HD: “Heavy Duty” reinforced assembly
DISC ON HUB
RIM ON DISC
Power front axle
wheels
Fixed cast iron wheels Steel wheels
Front axle
2 WD 200 to 260 Nm - - -
4 WD
(M18) 400 to 450 Nm
(M22) 640 to 680 Nm
- - 200 to 260 Nm
Rear axle -
Flanged shaft 350 to 460 Nm 180 to 250 Nm -
Straight shaft 350 to 460 Nm 180 to 250 Nm -
Power take-off shaft: 69 Nm
Engine oil drain plug: 35 Nm
