6 . SPECIFICATIONS
6.13
Challenger MT500B EU
6
6.23 - DIMENSIONS AND ATTACHMENT POINTS
6.23.1 - Specifications for MT555B / MT565B / MT575B series tractors
Fig. 4
15 M16 834 +/-252 -328.7
16 M16 834 +/-162 -368.7
17 M16 834 +/-252 -368.7
18
M16 ∅ 17X11
1646.8 +/-585 -9.7
19
M16
∅ 17X11
1646.8 +/-705 -9.7
20
M16 ∅ 17X36
1646.8 +/-595 -239.7
21
M16
∅ 17X36
1646.8 +/-675 -239.7
22
M16 ∅ 17X36
1776.8 +/-595 -239.7
23
M16
∅ 17X36
1646.8 +/-675 -239.7
24
M16 ∅ 17X11
1776.8 +/-585 -9.7
25
M16
∅ 17X11
1776.8 +/-705 -9.7
26
M20 ∅ 21X1.5
1641.8 +/-150 -280
27
∅ 20 1676.8 +/-150 -280
28
M20 ∅ 21X1.5
1711.8 +/-150 -280
REFERENCE DIMENSIONS (mm)
0= Engine axis x y z
REFERENCE DIMENSIONS (mm)
0= Engine axis x y z
1 M 20 -1572.3 +/-280 -20
2 M 20 -1572.3 +/-280 81.3
3 M 20 -1470.7 +/-280 -20
4 M 20 -1470.7 +/-280 81.3
5 M 20 -1022.7 +/-275 20.3
6 M 20 -1022.7 +/-275 -93.7
7 M 20 56.5 +/-274 -206.3
8 M 20 56.5 +/-274 -146.3
9 M 20 56.5 +/-274 -44.7
10 M16 260 +/-240 -71.7
11 M16 361.8 +/-240 -71.7
12 M16 260.2 +/-220 -173.3
13 M16 361.8 +/-220 -173.3
14 M20 834 +/-177 -328.7
Z2-292-06-03
12
5
3
1
13
10
9
22
17
16
21
20
23
26
25
15
24
18
19
14
11
8
7642
27 28
364
130 763
893
370
925
176
696
650
792
490
190
125
365
327
276
180
4132
*
0
z
x
y
Dimensions in relation to point 0
