7 . ACCESSORIES AND OPTIONS
7.33
Challenger MT500B EU
7
- spool valve parameters (see EHS VALVES applica-
tion),
- DUAL parameters (see FRONT DUAL, REAR DUAL,
TIC and POINTS applications).
NOTE: When a memory is active, the ON icon is dis-
played in the window. Example (Fig. 35).
NOTE: If a memory is active, its name is displayed in the
window (example 31 Fig. 36) when the MEMORIES
application is selected.
7.9 - WORK APPLICATION
7.9.1 - General
This application is used to display various parameters
stored for tractor use. A certain number of parameters are
fixed (Fig. 38, upper part of the screen) while others can be
selected by the user (right- and left-hand windows on
screen).
To start the WORK application (Fig. 37):
• Rotate the encoder (1) to the WORK application and
press the encoder once the active function is high-
lighted by red text and a red rectangle around the icon
(on b/w screens the elements are highlighted in reverse
video). Or press the key
«
1
(2). The window (Fig. 38) is
displayed.
• To exit an application, press the ESC key (3).
1
5
4
3
2
6
ON
DUAL CTRL AR
DUAL CTRL AV
Z3A-937-08-04-B
Fig. 35
PLOUGH
SELF LOADING TRAILER
DISC TILLER
SUBSOILER
SPREADER
ROTARY HARROW
1
2
3
4
5
6
ESC
Z3A-893-08-04
Fig. 36
WORK
SETTINGS
HEADLAND DUAL CTRL
MEMORIES
EHS VALVES
DISC TILLER
31
1
2
3
4
5
6
ESC
Z3A-782-08-04
Fig. 37
WORK
SETTINGS
HEADLAND DUAL CTRL
MEMORIES
EHS VALVES
3
2
1
