7 . ACCESSORIES AND OPTIONS
7.12
Challenger MT500B EU
7.2.8 - Comparative mode
(Fig. 10)
•Select -COMP. MODE- in the function menu: a second
menu appears.
• Turn the knob 14 to select, for example, the
-ENGINE RPM- line, and press key 2 or 3. The
Datatronic displays the same function on both half-
screens. The upper part displays the stored data, the
lower part displays the real working data, and the LED
flashes.
• When the required working conditions are entered,
press the memory key ref.10; the new data is stored in
the upper window.
• Other data can also be stored (engine speed, forward
speed, etc.) by carrying out this operation.
The value is stored in memory until a new value is record-
ed.
• To quit the comparative mode, press key 2 or 3 to return
to the menu.
•Select -END- by turning the knob 14 (Fig. 11). Press 2 or
3 again to display the active mode data.
2
3
14
FUEL USED
AREA WORKED
DISTANCE
HRS WORKED
COUNTER
COMP. MODE
EXT. TEMP.
TIME
DATE
SERVICE
COST/L
2
3
ENGINE RPM
PTO 540 RPM
PTO 1000 RPM
FWD SPEED
WHEEL SLIP
COST/AREA
AREA/HOUR
FUEL/HOUR
FUEL/AREA
Fig. 10
V914
V922
V922
10
4. PLOUGH.
14
2
3
Fig. 11
V922
ENGINE RPM
PTO 540 RPM
PTO 1000 RPM
FWD SPEED
WHEEL SLIP
COST/AREA
AREA/HOUR
FUEL/HOUR
FUEL/AREA
END
