Appendix A Specifications
Managed System Resources
Managed System Resources
Table A-3 lists the managed system resources of the FWSM. You can manage these resources per context
using the resource manager. See the “Configuring Resource Management” section on page 5-11.
Table A-3 Managed System Resources
Specification
Context Mode
Single Multiple
MAC addresses (transparent
firewall mode only)
64,000 64,000 divided between all contexts
Hosts allowed to connect
through the FWSM, concurrent
256,000 256,000 divided between all contexts
Inspection engine connections,
rate
10,000 per second 10,000 per second divided between all contexts
IPSec management
connections, concurrent
5 5 per context
Maximum of 10 divided between all contexts
PDM management sessions,
concurrent
1
1. PDM sessions use two HTTPS connections: one for monitoring that is always present, and one for making configuration
changes that is present only when you make changes. For example, the system limit of 32 PDM sessions represents a limit of
64 HTTPS connections.
5 Up to 5 per context
Maximum of 32 divided between all contexts
NAT translations, concurrent 256,000 256,000 divided between all contexts
SSH
2
management
connections, concurrent
2. Secure Shell
5 5 per context
Maximum of 100 divided between all contexts
System messages, rate 30,000 per second
for messages sent to
the FWSM terminal
or buffer
25,000 per second
for messages sent to
a syslog server
30,000 per second divided between all contexts
for messages sent to the FWSM terminal or
buffer
25,000 per second divided between all contexts
for messages sent to a syslog server
TCP
3
or UDP
4
connections
between any two hosts,
including connections between
one host and multiple other
hosts, concurrent and rate
5
3. Transmission Control Protocol
4. User Datagram Protocol
5. Because Port Address Translation (PAT) requires a separate translation for each connection, the effective limit of connections
using PAT is the translation limit (256,000), not the higher connection limit. To use the connection limit, you need to use
NAT, which allows multiple connections using the same translation session.
999,900
100,000 per second
999,900 divided between all contexts
100,000 per second divided between all
contexts
Telnet management
connections, concurrent
5 5 per context
Maximum of 100 connections divided between
all contexts.
