Modules
6 - 12 Setting Up SATA RAID, Optane™ or AHCI Mode
6
RAID Setup (2 * PCIE SSDs) - UEFI Enabled
If you are setting up a RAID using 2 * PCIE SSDs, with the Windows 10 OS in-
stalled on one of them, then follow the setup procedure below:
To configure your RAID (Redundant Array of Independent Disks) system in Strip-
ing (RAID 0) or Mirroring (RAID 1) modes (see Table 6 - 1, on page 6 - 5) you will
require two identical solid state drives.
You need to setup a RAID before installing your Windows 10 operating system, and
you will need to prepare the following in order to do so.
==========================================================
•The Microsoft Windows 10 OS DVD.
• An connected external DVD drive.
• Two Identical PCIe solid state drives.
•The Device Drivers & Utilities + User’s Manual disc.
• A USB flash drive.
• An operable computer (to copy files from the Device Drivers & Utilities +
User’s Manual disc to the USB flash drive).
==========================================================
Before setting up the system you will need to copy a driver folder to a USB flash
drive. This driver folder is included on the Device Drivers & Utilities + User’s Man-
ual disc but you will need to go to an operable computer and copy the folder to a
USB Flash drive.
