Specifications
D - 2 Specifications
D
Note
Core Logic
Intel® Z370 Express Chipset
Display
Models A & B:
15.6" (39.62cm) UHD (3840 * 2160) /
FHD (1920 * 1080), 3.2mm, 16:9 Backlit
Panel
Models C & D:
17.3" (43.94cm) FHD (1920 * 1080) /
*QHD (2560 * 1440) / *UHD (3840 *
2160), 4.0mm, 16:9 Backlit Panel
*Note: QHD/UHD panels are available for
systems with NVIDIA® G-SYNC™ Technology
only
CPU Speed & Computer in DC Mode
Note that when the computer is in DC mode
(powered by the battery only) the CPU may
not run at full speed. This is a design feature
implemented in order to protect the battery.
Memory
Dual Channel DDR4
Four 260 Pin SO-DIMM Sockets
Supporting DDR4 2400 MHz Memory
Modules (real operational frequency
depends on the FSB of the processor)
Memory Expandable from 8GB
(minimum) up to 64GB (maximum)
Compatible with 4GB/8GB/16GB Modules
Supports XMP 2400/2666/3000 MHz
(XMP support depends on the processor
and works with
four
DIMMS Dual Channel
OR
two
DIMMS Single Channel)
Channel A = RAM 1 & RAM 3 slots
Channel B = RAM 2 & RAM 4 slots
(Check with your distributor/supplier for
RAM installation details)
SO-DIMM Memory Types
All SO-DIMM memory modules installed in the
system should be identical (the same size and
brand) in order to prevent unexpected system
behavior.
Do not mix SO-DIMM memory module sizes
and brands otherwise unexpected system
problems may occur.
Storage
Two Changeable 2.5" 7mm/9.5mm (h)
Hard Disk Drives (HDD) / Solid State
Drives (SSD) with SATA Interface (RAID
0/1)
Two M.2 2280 SSDs with SATA / PCIe
Gen3x4 Interface (RAID 0/1) (Factory
Option)
BIOS
One 64Mb SPI Flash ROM
AMI BIOS
Audio
High Definition Audio
S/PDIF Digital Output
Built-In Array Microphone
2 Built-In 2W Speakers
Sound Blaster® X-Pro Gaming 360°
ESS™ SABRE HIFI DAC for high
resolution headphone audio
External 7.1CH Audio Output Supported
By 2-In-1 Audio, Microphone, Line-In &
Line-Out Jacks
For Models C & D Only:
One Built-in Subwoofer Speaker
To Next Page
