Specifications
Specifications D - 3
D
Keyboard & Pointing Device
Full Size Color Illuminated Keyboard with
Numeric Keypad & Anti-Ghost Keys
Built-In Secure Pad with Microsoft PTP
Multi Gesture & Scrolling Functionality
W/A/S/D Game Keys
Indicators
LED Indicators - Power/Suspend, Battery,
HDD, Airplane Mode, Num Lock, Caps
Lock, Scroll Lock, Camera
Interface
One USB 3,1 Gen 2 Port (Type C)
One USB 3.1 Gen 2 Port (Type C) /
Thunderbolt™ 3 Combo Port - (Note
Thunderbolt output requires BIOS setting)
===============================
*Note: The maximum amount of current supplied
by USB Type-C ports is 500 mA for USB2.0/900
mA for USB 3.1
===============================
Two Mini Display Ports 1.3 (Note one DP port
will be disabled if Thunderbolt enabled)
One HDMI™ (High-Definition Multimedia
Interface) Out Port (with HDCP)
One Microphone-In Jack
One 2-In-1 Audio Jack - (Headphone /S/
PDIF Optical Output)
One Line-In Jack
One Line-Out Jack
One RJ-45 LAN
Jack
One DC-In Jack
For Models A & B Only:
One USB 2.0 Port
Three USB 3.0 Ports (USB 3.1 Gen 1 -
incl AC/DC powered USB3.0 Port)
For Models C & D Only:
Four USB 3.0 Ports (USB 3.1 Gen 1 - incl
AC/DC powered USB3.0 Port)
Card Reader
Embedded Multi-In-1 Push-Push Card
Reader
- MMC / RSMMC
- SD/ Mini SD / SDHC / SDXC (up to UHS-II)
Card Reader Note: Some cards require
adapters usually supplied with the cards.
Card Slots
Four M.2 Slots for Models A & B
OR
Three:M.2 Slots for Models C & D
Slot 1:
for M.2 2230 WLAN Combo Module
Card with PCIe * 2 & USB Interfaces (A
Key)
Slot 2:
for M.2 2280
SSD
Card
with SATA/
PCIe Gen3x4 Interface (M Key)
Slot 3:
for M.2 2280
SSD
Card
with SATA/
PCIe Gen3x4 Interface (M Key)
=======================================
(
For Models A & B Only
):
LTE or UTMS/HSPA+ M.2 3042
3G or 4G
Module
Card
with USB Interface (B Key)
Note: LTE-1 / 802.11AD Antenna (
Factory
Option
) - LTE cannot coexist with 802.11AD
