DESIGNER’S HANDBOOK 4189350049C EN Page 105 of 206
9.1 Surveyor information (INFO)
Press button 1 and 2 for more than 5 seconds, and the surveyor page will provide information about the XDi and its
configuration.
1
Serial number and software information
2
CAN bus settings
3
Information about extension modules (if mounted)
4
Library owner and library number
5
Active virtual indicator number
6
Thumbnail picture of the active virtual indicator
7
Wheel-mark if the active virtual indicator is MED-compliant.
The figures to the right of the wheel-mark indicates the notified
approval body no. (0098 – DNV GL) and the production year of the
actual XDi unit (in the screen above it is 14, corresponding to
2014).
9.2 Master reset
Press button 1 and 3 for 5 seconds, and the master reset menu will appear.
