Installing the system fan
1. Align the system fan to its slot on the system board and secure it with the 3 screws.
2. Connect the fan cables to the slot on the system board.
3. Install the:
a. graphical processing unit(GPU)
b. 5.25 ODD bracket
c. front bezel
d. air shroud
e. side cover
4. Follow the procedure in After working inside your computer.
Fan bracket
Removing the fan from the fan bracket
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. side cover
b. system fan
3. To remove the fan from the fan bracket:
a. Slide out the four rubber grommets for each fan from the fan chassis [1].
b. Lift the fan and remove it from the fan assembly [2].
Removing and installing components
55
