Dell E30S002 User Manual

Figure 72. Installing a power supply unit blank
Next step
Follow the procedure listed in After working inside your system.
Removing a power supply unit
Prerequisites
CAUTION: The system needs one power supply unit (PSU) for normal operation. On power-redundant systems, remove and
replace only one PSU at a time in a system that is powered on.
1 Follow the safety guidelines listed in Safety instructions.
2 Disconnect the power cable from the power source and from the PSU you intend to remove, and then remove the cable from the
strap on the PSU handle.
Step
Press the orange release latch and slide the PSU out of the system by using the PSU handle.
Figure 73. Removing a power supply unit
Next step
Install the PSU.
Related link
Installing redundant power supply unit
Installation and Service Manual
Installing and removing system components
125

Dell E30S002 Specifications

General

Brand	Dell
Model	E30S002
Category	Server
Language	English
