Table 31. Memory population
DIMM Type DIMMs Populated/
Channel
Voltage
Operating Frequency (in
MT/s)
Maximum DIMM Rank/Channel
RDIMM 1
1.2 V
2666, 2400, 2133, 1866 Dual rank or single rank
2 2666, 2400, 2133, 1866 Dual rank or single rank
LRDIMM 1
1.2 V
2666, 2400, 2133, 1866 Quad rank
2 2666, 2400, 2133, 1866 Quad rank
General memory module installation guidelines
NOTE: If your system's memory congurations fail to observe these guidelines, your system might not boot, might stop
responding during memory conguration, or might operate with reduced memory.
The system supports Flexible Memory Conguration, enabling the system to be congured and run in any valid chipset architectural
conguration. The following are the recommended guidelines for installing memory modules:
• RDIMMs and LRDIMMs must not be mixed.
• x4 and x8 DRAM based memory modules can be mixed. For more information, see the Mode-specic guidelines section.
• Up to two RDIMMs can be populated per channel regardless of rank count.
• Up to two LRDIMMs can be populated per channel regardless of rank count.
• If memory modules with dierent speeds are installed, they will operate at the speed of the slowest installed memory module(s) or
slower depending on the system DIMM conguration.
• Populate memory module sockets only if a processor is installed. For single-processor systems, sockets A1 to A10 are available. For dual-
processor systems, sockets A1 to A10 and sockets B1 to B6 are available.
• Populate all the sockets with white release tabs rst, followed by the black release tabs.
• When mixing memory modules with dierent capacities, populate the sockets with memory modules with the highest capacity rst. For
example, if you want to mix 8 GB and 16 GB memory modules, populate 16 GB memory modules in the sockets with white release tabs
and 8 GB memory modules in the sockets with black release tabs.
• In a dual-processor conguration, the memory conguration for each processor should be identical. For example, if you populate socket
A1 for processor 1, then populate socket B1 for processor 2, and so on.
• Memory modules of dierent capacities can be mixed provided other memory population rules are followed (for example, 8 GB and 16
GB memory modules can be mixed).
• Mixing of more than two memory module capacities in a system is not supported.
• Populate six memory modules per processor (one DIMM per channel) at a time to maximize performance.
Mode-specic guidelines
Six memory channels are allocated to each processor . The congurations allowed depend on the memory mode selected.
98
Installation and Service Manual
Installing and removing system components
