Figure 15. Removing the system feet
Next step
If applicable, install the system feet or the caster wheel assembly.
Related link
Installing the system feet
Installing caster wheels
Installing the system feet
Prerequisites
CAUTION
: Install the feet on a stand-alone tower system to provide stability to the system. An unstable system might tip over
and cause injury to the user or damage to the system.
1 Follow the safety guidelines listed in Safety instructions.
2 Place the system on its side, on a at, stable surface.
Steps
1 Align the three tabs on the system foot with the three slots on the base of the system.
2 Using the Phillips #2 screwdriver, secure the screw that secures the foot to the base of the system.
a Repeat the above steps to install the remaining system feet.
Installation and Service Manual
Installing and removing system components
63
