Figure 81. Removing the control panel assembly
4 To remove the information tag, perform the following steps:
a Locate and press the tabs on the information tag.
b Push the information tag out of the slot to remove it from the control panel.
NOTE
: Retain the information tag to replace it in the new control panel.
Installing the control panel assembly
Prerequisite
Follow the safety guidelines listed in Safety instructions.
Steps
1 Replace the blank information tag in the new control panel with the information tag retained from the old control panel.
132
Installation and Service Manual
Installing and removing system components
