Installing and removing system components
Safety instructions
WARNING: Whenever you need to lift the system, get others to assist you. To avoid injury, do not attempt to lift the system by
yourself.
WARNING: Opening or removing the system cover while the system is powered on may expose you to a risk of electric shock.
CAUTION: Do not operate the system without the cover for a duration exceeding ve minutes. Operating the system without the
system cover can result in component damage.
CAUTION: Many repairs may only be done by a certied service technician. You should only perform troubleshooting and simple
repairs as authorized in your product documentation, or as directed by the online or telephone service and support team. Damage
due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that are
shipped with your product.
NOTE: It is recommended that you always use an antistatic mat and antistatic strap while working on components inside the
system.
CAUTION: To ensure proper operation and cooling, all bays in the system and system fans must be always populated with a
component or a blank.
Before working inside your system
Prerequisite
Follow the safety guidelines listed in Safety instructions.
Steps
1 Turn o the system, including all attached peripherals.
2 Disconnect the system from the electrical outlet and disconnect the peripherals.
3 Lay the system on its side.
4 Remove the system cover.
Related link
Removing the system cover
After working inside your system
Prerequisite
Follow the safety guidelines listed in Safety instructions.
Steps
1 Install the system cover.
2 Place the system upright on a at, stable surface.
3 Reconnect the peripherals and connect the system to the electrical outlet.
4 Turn on the attached peripherals and then turn on the system
Related link
Installing the system cover
6
60 Installation and Service Manual
Installing and removing system components
