Dell EMC PowerEdge C6420 User Manual

Installing a mezzanine card
Prerequisite
NOTE: The procedure to install the mezzanine blank is similar to the removal of a mezzanine card.
1 Follow the safety guidelines listed in Safety instructions.
Steps
1 Attach and secure the mezzanine card bracket to the mezzanine card.
2 Holding the card by its edges, position the card so that the card edge connector aligns with the connector of the bridge board on the
system board.
3 Insert the card edge connector and push the card rmly until the card is fully seated on the bridge board.
4 Using the Phillips #2 screwdriver, secure the mezzanine card and bracket assembly to the sled using screws.
108 Installing and removing system components

Dell EMC PowerEdge C6420 Specifications

General

Processor	Intel Xeon Scalable processors
Management	iDRAC9
Max Processors	2 per node
Memory	DDR4
Storage	Up to 6 x 2.5" drives
Drive Bays	24 x 2.5" or 12 x 3.5"
Network	2 x 10GbE ports per sled
Power Supply	Dual, 2000W
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
Maximum RAM	Up to 3TB per node
Max Memory	Up to 3TB per node
