Dell EMC PowerEdge C6420 User Manual

Figure 15. Installing a sled blank
Next step
Follow the procedure listed in After working inside your system.
NOTE
: To add the Service Tag of the system board to match the Service Tag of the physical node, contact Dell Technical
Support.
PERC battery
Removing the PERC battery
Prerequisites
1 Follow the safety guidelines listed in Safety instructions.
2 Follow the procedure listed in Before working inside your system.
3 Remove the sled from the enclosure.
4 If applicable, disconnect the battery cable from the PERC card.
CAUTION
: Do not hold the battery cable and lift the battery out.
Step
Holding the cable end of the battery, lift the battery out of the air shroud.
Installing and removing system components
67

Dell EMC PowerEdge C6420 Specifications

General

Processor	Intel Xeon Scalable processors
Management	iDRAC9
Max Processors	2 per node
Memory	DDR4
Storage	Up to 6 x 2.5" drives
Drive Bays	24 x 2.5" or 12 x 3.5"
Network	2 x 10GbE ports per sled
Power Supply	Dual, 2000W
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
Maximum RAM	Up to 3TB per node
Max Memory	Up to 3TB per node
