Dell EMC PowerEdge C6420 User Manual

5 Run the system memory test in system diagnostics.
Support bracket
Removing the support bracket
Prerequisites
1 Follow the safety guidelines listed in Safety instructions.
2 Follow the procedure listed in Before working inside your system.
3 Remove the sled from the enclosure.
Step
Using the Phillips #1 screwdriver, remove the screws that secure the support bracket and lift the bracket away from the sled.
Figure 23. Removing the support bracket
Next step
Install the support bracket.
Related link
Removing a sled
Installing the support bracket
Installing the support bracket
Prerequisite
1 Follow the safety guidelines listed in Safety instructions.
Step
Insert the support bracket onto the sled and use the Phillips #1 screwdriver to secure the bracket in place with screws.
Installing and removing system components
75

Dell EMC PowerEdge C6420 Specifications

General

Processor	Intel Xeon Scalable processors
Management	iDRAC9
Max Processors	2 per node
Memory	DDR4
Storage	Up to 6 x 2.5" drives
Drive Bays	24 x 2.5" or 12 x 3.5"
Network	2 x 10GbE ports per sled
Power Supply	Dual, 2000W
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
Maximum RAM	Up to 3TB per node
Max Memory	Up to 3TB per node
