Delta Electronics A10 User Manual

Revision Apr. 30th, 2007, 2007PDD23000002 1-1
Chapter 1 Introduction
1.1 DOP Series Human Machine Interface
DOP series HMI are manufactured by adopting high-speed hardware to provide you with a powerful
programmable interface. ScrEdit software is a user-friendly program editor of DOP-A, DOP-AE and DOP-AS
series HMI for Windows. Please refer to the following section for its features and function introduction.
1.2 Features
 PLC Serial Drives Support
DOP series HMI’s support more than twenty brands of PLC’s, including Delta, Omron, Siemens,
Mitsubishi, etc. All of the newly supported PLC’s communication protocol information could be found on
our website (http://www.delta.com.tw/industrialautomation/) for upgrade to meet your requirements. (All
other trademarks in this manual are property of their respective companies.)
 Windows® Fonts Support for ScrEdit Software
Except Simplified Chinese, traditional Chinese and English languages, ScrEdit software also provides
those fonts that Windows® uses.
 Quick Execution and Communication Macro
It can handle complicated calculation by executing macro. The user can also write communication
protocol with communication macro command to connect specific system via COM port.
 Rapid USB Upload/Download
It will shorten upload/download time by using USB Ver1.1.
 Recipes
It provides useful recipe editor that is similar to Microsoft excel for user to edit recipe easily and input
multiple recipes simultaneously (size limit is 64K). When downloading multiple recipes at the same time,
it can exchange by internal memory of HMI. If data has finished editing when downloading, you can
download recipe individually.
 Direct Communication with Two or Three PLCs
DOP-A series HMI is able to connect to two different or the same controllers via two communication
ports. Up to three communication ports are provided in DOP-AE and DOP-AS series HMI for direction
connection to PLCs.

Delta Electronics A10 Specifications

General

Brand	Delta Electronics
Model	A10
Category	Monitor
Language	English

Summary

Chapter 1 Introduction - Features

Chapter 1 Introduction - Cautions

Chapter 2 Creating and Editing Screens

2.1 ScrEdit (Screen Editor) Setup

Guides the user through the initial setup and system requirements for ScrEdit.

2.2 How to Start ScrEdit

Explains how to launch and start the ScrEdit application.

2.3 Menu Bar and Toolbar (File)

Details the functions within the File menu of the Menu Bar.

2.4 Menu Bar and Toolbar (Edit)

Details the functions available in the Edit menu.

2.5 Menu Bar and Toolbar (View)

Explains how to customize the display of toolbars and windows.

2.6 Menu Bar and Toolbar (Element)

Details the Element menu for adding graphical and functional components.

2.7 Menu Bar and Toolbar (Screen)

Details functions for managing screens within the project.

2.8 Menu Bar and Toolbar (Tools)

Details functions available in the Tools menu.

2.9 Menu Bar and Toolbar (Options)

Accesses various configuration and setting menus.

2.10 Menu Bar and Toolbar (Window)

Options for managing multiple open windows and screens.

2.11 Menu Bar and Toolbar (Help)

Accesses help resources and software information.

Chapter 3 Element Function

3.1 How to Choose Element

Explains methods for selecting and adding elements to screens.

3.2 Button Element

Details the properties and functions of Button elements.

3.3 Meter Element

Element for displaying values using a meter gauge.

3.4 Bar Element

Element for displaying values using a bar graph.

3.5 Pipe Element

Element for displaying fluid levels or flow in pipes.

3.6 Pie Element

Element for displaying data as a pie chart.

3.7 Indicator

Element used for displaying status or state indications.

3.8 Data Display

Covers various elements for displaying data.

3.9 Graph Display

Elements for displaying graphical data.

3.10 Input Display

Elements for user input and data display.

3.11 Curve Element

3.12 Sampling Element

3.13 Alarm Element

3.14 Graphic Element

3.15 Keypad Element

Chapter 4 Macro Function

4.1 Macro Type

4.2 Macro Editing

4.3 Macro Operation

4.4 Error Messages

Chapter 5 Control Block and Status Block

5.1 Control Block

5.2 Status Block

Chapter 6 Internal Memory

Receipt Number Register (R/W): RCPNO

Receipt Register (R/W): RCP

Appendix A Specifications and Installation

A.1 Specifications

A.3 Installation

Appendix B USB Flash Drive Update Function

Upgrade Firmware

Copy screen data from a USB flash drive to HMI

Appendix C Main Menu Operation of HMI System

COM Port Upload and Download
