AS Series Operation Manual
7-4
_7
7.3.2 Installing a Memory Car
d
Insert a memory card into the CPU module memory card slot and push it in until it clicks. Be sure the memory
card is fixed firmly in the slot; if the memory card is loose, it is not installed correctly. The memory card can
only be inserted in one direction. Do not force the memory card or you may damage the CPU module. The
correct way to insert the memory card is shown below.
7.3.3 Removing a Memory Card
You can remove a memory card by pushing it in. The card then springs from the slot.
7.4 Memory Card Contents
7.4.1 Initializing a Memory Card
When you insert an SDHC card into a CPU module that is powered on, and use ISPSoft -> CARD Utility to
back up a project, the system initializes the SDHC card, and creates a default folder named according to the
model of the CPU module. (If the folder is already existed, the system does not create a second folder for the
same model.)
When the system initializes an SDHC card, it automatically adds any missing folders to the directory structure.
However, if the initialization of a SDHC card fails, you cannot initialize the SDHC card again until you reformat
it.
When you initialize a memory card, the SYSTEM indicator in the software blinks.
