AS Series Operation Manual
9-78
_9
9.8.7 Port Object (Class ID: F4 Hex)
This section describes the communication interfaces that are present on the device and visible to CIP, including USB,
EtherNet/IP and more.
 Service Code
Service
Code
Service Name
Support
Description
Class Attribute Instance Attribute
H’01 Get_Attributes_All X V
Returns a predefined listing of this
objects’ attributes
H’0E Set_Attribute_Single V V
Returns the contents of the
specified attribute.
 Class
 Class ID：H’F4
 Instance
 H’00：Class Attribute
 H’01：Instance Attribute
 H’N: Instance #N Attribute, the number of the Ethernet port
 When Instance = 0, the Class Attributes are listed below.
Class
Attribute
Name
Access
Rule
Data Type Values Description
H’01 Revision Get UINT
1
Revision of this object
H’02 Max Instance Get UINT
1
Maximum instance number of this
object
H’03 Number of Instance Get UINT
1
Number of object instances
currently created at this class level
of the device
H’08 Entry Port Get UINT
1
Communication port for EtherNet/IP
H’09 Port Instance Info Get
ARRAY of
STRUCT of
--
Port Instance information: Port Type
+ Port Number
