AS Series Operation Manual
9-12
Item AS300 Series AS200 Series Remarks
Number
Max. Data Length
500 bytes (IO Connection)
400 bytes (Explicit Message)
Requested Packet
Interval (RPI)
5 ms – 1000 ms
Maximum number of connections when using AS300 to connect to other devices through Ethernet/IP:
AS300 can act as a Scanner and an Adapter simultaneously. It can connected up to 16 devices (for example 8
Scanners and 8 Adapters).
When AS300 acts as a Scanner, it can connect to up to 16 devices. Each device can establish up to 32
connections for data mapping. Data mapping types can be I/O connection and Consumed TAG. You can use
explicit message for data mapping at the same time, up to 16 explicit message connections can be created.
When AS300 acts as an Adapter, it can connect to up to 16 devices. Each device can establish up to 8
connections for data mapping. Data mapping types can be I/O connection and Produced TAG. You can use explicit
message for data mapping at the same time, up to 8 explicit message connections can be created.
9.3.3 PROFINET Specification
Item Specification
Communication Protocol PROFINET RT
EtherNet/IP Interface 100 Mbit with 2 x RJ45
Fieldbus
PROFINET Devices
Network Cable Length 100 meter
Error Indicator System Fail (SF): Red; Bus Fail (BF): Red
Max. Connection Number
17
Register to Read and Write AS300 series data registers are supported to read and write
Minimum Time for Data Exchange to Operate 10 ms
Maximum Data Length/Per Transmission
Input: 250 words
Output: 250 words
PROFINET Configuration Download PROFINET Configurations from PN Controller
