Delta DVP-ES3 Series User Manual

Chapter 9 Ethernet Specification and Operation
9-45
9_
Instance
Attribute
Name
Access
Rule
Data Type Values Description
H’03 Number Active Get UINT H’0
The number of connected
connections
9.7.5 Assembly Object (Class ID: 04 Hex)
This object binds attributes of multiple objects, which allows data to or from each object to be sent or received over a
single connection and can be used to bind input data or output data.
 Service Code
Service
Code
Service Name
Support
Description
Class Attribute Instance Attribute
H’0E Get_Attribute_Single V V Read a single attribute
H’10 Set_Attribute_Single X V Edit a single attribute
 Class
 Class ID：H’04
 Instance
 H’00：Class Attribute
 H’64：I/O Connection Output 1
 H’65：I/O Connection Input 1
 H’66：I/O Connection Output 2
 H’67：I/O Connection Input 2
 H’72：I/O Connection Output 8
 H’73：I/O Connection Input 8
 H’74-H’7A Reserved
 H’80：Configuration 1
 H’81：Configuration 2
 H’87：Configuration 8
 H’C：Listen-Only Connection Number
