2.6.3 Installation and Wiring
 Use DVPAEXT01-E2 (DVPAEXT1R-E2 + DVPAEXT1L-E2) to extend the connections
Since the installation space is limited, you can use DVPAEXT01-E2 (DVPAEXT1R-E2 + DVPAEXT1L-E2) to
extend the communication signal and the connection between DVP-ES2/EX2 series CPU and the DI/DO or
AI/AO extension modules.
DVPAEXT1L-E2
DVPAEXT1R-E2
 Pin Definition
Use the enclosed cable to connect DVPAEXT1R-E2 and DVPAEXT1L-E2.
1 2 3 4 5
6 7 8 9
1 2 3 4 5
6 7 8 9
