Chapter 11 CPU Module Operating Principle
11-3
11
11.1.2 I/O Refreshing and Communication Service
 Refreshing I/O
The CPU module reads external I/O data periodically or outputs data to an external I/O. Refreshing the
I/O includes the following.
 Refreshing data in a digital I/O module
 Refreshing data in an analog I/O module
 Refreshing data in a network module
All I/O refreshing executes in the same loop. The data in an input device refreshes before a program
executes, and the data in an output device refreshes after the program executes.
Unit Maximum data exchange Data exchange area
Digital I/O module
Depends on the number of input/output
channels in the unit.
Input relay/Output relay
Analog I/O module
Depends on the number of input/output
channels in the unit.
Data register
Network module Depends on the unit. Data register
 Communication service
Communication service is the unscheduled communication service for a network module. It includes the
communication requests sent from external equipment to a CPU module, and the communication requests
sent from the CPU module to the external equipment.
