Delta DVP-ES3 Series User Manual

Chapter 2 Specifications and System Configuration
2-4
2_
Item
DVP32ES311T, DVPxxES300T, DVPxxES300R
Remark
Supporting Modbus TCP and Ethernet/IP Adapter
protocols
9.3 for more details on
Ethernet
specificaitons
USB port
Mini B type USB
Storage interface
SD Card (Micro SD); maximum storage: 32G
Real-time clock
Years, months, days, hours, minutes, seconds and
weeks
Active about one
week, storing in an
electric double layer
capacitor
CANopen DS301 (Master)
Maximum node: 64; maximum bytes: 2000
Built-in CAN
communication port
CANopen DS301 (Slave)
Maximum PDO: 8; maximum bytes: 8
2.2.2 Electrical specifications
Model
Item
DVP32ES311T
Supply voltage
24 VDC (20.4 VDC–28.8 VDC) (-15% to +20%)
Weight (g)
390 g
 Electrical specifications for the inputs on digital input/output module. The signals passing through
the inputs are 24 VDC signals.
Model
Item
DVP32ES311T
DVP32ES300T
DVP32ES300R
DVP48ES300T
DVP48ES300R
DVP64ES300T
DVP64ES300R
DVP80ES300T
DVP80ES300R
Number of
inputs
16 (X0 ~ X17) 24 (X0 ~ X27) 32 (X0 ~ X37) 40 (X0 ~ X47)
Connector type
Removable terminal blocks
Input type
Digital input
Input form
Direct current (sinking or sourcing)
Input voltage/
current
X0 ~ X7: 24VDC, 5.8mA
X10 ~ X47: 24VDC, 4mA
Act
ion
level
OFF→ON
>15 VDC
ON→OFF
<5 VDC
Respo
nse
time
OFF→ON
X0 ~ X7: 1.5μs
X10 ~ X17: 15μs
X20～X47: 10ms
ON→OFF
X0 ~X7: 1.5μs
X10 ~ X17: 15μs
X20～X47: 10ms
Maximum input
frequency
X0 ~ X7: 200kHz
X10 ~ X17: 20kHz
X20～X47: 50Hz
Input impedance
X0 ~ X7: 3.9kΩ
X10 ~ X47: 5.6kΩ
