Delta DVP-ES3 Series User Manual

Chapter 2 Specifications and System Configuration
2-22
2_
2.5 Temperature Measurement Modules Specifications
2.5.1 General Specifications
 DVP04PT-E2/DVP06PT-E2
Electrical specifications
Model Name
DVP04PT-E2
DVP06PT-E2
Number of inputs
Four Six
Supply voltage
24 VDC (20.4 VDC–28.8 VDC) (-15% to +20%)
Connector type
Removable terminal block (distance to the terminal is 5 mm)
Conversion time
200 ms /channel
Weight
207 g
176 g
Things to note when connecting the module to a CPU PLC module:
1. Up to 8 modules can be connected to a CPU PLC module.
2. The connected module is numbered automatically from 0 (nearest to the CPU PLC module) to 7
(furthest away from the CPU PLC module).
3. The connected modules do NOT take up any digital I/O points.
Functional specifications
Centigrade (°C) Fahrenheit (°F)
Input
impedance
Digital data format
16-bit two’s complement number
Overall accuracy
25°C/77°F: The error is ±0.3% of the input within the range.
0 to +55°C / 32 to 131°F: The error is ±0.6% of the input within the range.
Applicable sensor
04PT: 3-Wire Pt100 (DIN 43760-1980 JIS C1604-1989, 100Ω 3850 PPM/°C);
Pt1000 (DIN EN60751, 1 kΩ 3850 PPM/°C), Ni100/Ni1000 (DIN 43760
);
input impedence: 0 ~ 300Ω / 0 ~ 3000Ω
06PT: 3-Wire Pt100 (DIN 43760-1980 JIS C1604-1989, 100Ω 3850 PPM/°C);
Pt1000 (DIN EN60751, 1 kΩ 3850 PPM/°C), Ni100/Ni1000 (DIN 43760),
Cu50, Cu100, JPt100 (JIS C1604-1989), LG-Ni1000;
input impedence: 0
~ 300Ω / 0 ~ 3000Ω
Rated input range
Pt100: -180°C to +800°C
Ni100: -80°C to +170°C
Pt1000: -180°C to +800°C
Ni1000: -80°C to +170°C
JPt100: -180°C to +500°C
LG-Ni1000: -50°C to +180°C
Cu50: -50°C to +150°C
Cu100: -50°C to +150°C
Pt100: -292°F to +1,472°F
Ni100: -112°F to +338°F
Pt1000: -292°F to +1,472°F
Ni1000: -112°F to +338°F
JPt100: -292°F to +932°F
LG-Ni1000: -58°F to +356°F
Cu50: -58°F to +302°F
Cu100: -58°F to +302°F
0–300 Ω
0–3000 Ω
Analog-to-digital
conversion
Pt100: K-1,800 ~ K8,000
Ni100: K-800 ~ K1,700
Pt1000: K-1,800 ~ K8,000
Ni1000: K-800 ~ K1,700
JPt100: K-1,800 ~ K5,000
Cu50: K-500 ~ K1,500
Cu100: K-500 ~ K1,500
LG-Ni1000: K-500 ~ K1,800
Pt100: K-2,920 ~ K14,720
Ni100: K-1,120 ~ K3,380
Pt1000: K-2,920 ~ K14,720
Ni1000: K-1,120 ~ K3,380
JPt100: K-2,920 ~ K9,320
Cu50: K-580 ~ K3,020
Cu100: K-580 ~ K3,020
LG-Ni1000: K-580 ~ K3,560
K0 ~ K3,000
K0 ~ K30,000
Hardware resolution
16-bit (0.1°C) 16-bit (0.1°F) 16-bit (0.1 Ω)
