Ducati 998 User Manual

40
E
Checking the coolant level (fig. 28.1)
Check the coolant level in the expansion reservoir, on the
LH side of the motorcycle.
The coolant level must be between the MAX and MIN
marks.
Top up if the level is too low.
Remove the l.h. body panel and the fuel tank. Lift the tail
guard and undo the rear screw (2, fig. 28.2). Remove the
tank from its front clamping by pulling the tank
backwards. Move it to the right leaving fuel tubing
connected.
Unscrew the filler (1, fig. 28.1) and add a mixture
consisting of water and antifreeze SHEEL Advance
Coolant or Glycoshell (35-40% of the volume) up to MAX
mark.
Refit the filler (1) and reassemble all removed parts. This
mixture improves operating conditions (coolant will start
freezing at –20°C).
Coolant circuit capacity: 3.5 cu dm (liters).
Warning
Place the motorcycle on a flat surface and make
sure the engine is cold before proceeding.
fig. 28.2
fig. 28.1
ProCarManuals.com

Ducati 998 Specifications

General

Displacement	998 cc
Bore x Stroke	100 x 63.5 mm
Compression Ratio	11.4:1
Transmission	6-speed
Frame	Tubular steel trellis
Front Brakes	2 x 320 mm discs, 4-piston calipers
Seat Height	790 mm (31.1 in)
Engine Type	L-twin, 4-valve per cylinder, Desmodromic
Power	123 hp @ 9, 750 rpm
Front Suspension	Showa 43mm upside-down fork
Rear Suspension	Showa monoshock
Rear Brakes	220 mm disc, 2-piston caliper
Fuel Capacity	17 liters
