Ducati 998 User Manual

5a
1
c
b
8
3 7 4 2 6
D
U
C
A
T
I
C
O
R
S
E
11
E
Instrument panel (fig. 3)
1) Speedometer (km/h or mph).
Gives road speed.
a) Odometer (km or miles).
Gives total distance covered.
b) Trip meter (km or miles).
Gives distance covered since last resetting.
c) Trip meter resetting knob.
Turn to reset trip meter to “0000”.
2) Engine revolution meter (rpm)
Indicates engine rpm.
3) Green light N.
Comes on when gearbox is in neutral.
4) Yellow light .
Comes on when there are about 4 liters fuel left in the
tank.
5) Green light .
Comes on and flashes when a turn indicator is on.
6) Red light .
Comes on when engine oil pressure is too low. It comes
on when the ignition is switched to ON and normally
goes out a few seconds after engine starts.
It may shortly come on when the engine is hot, however,
it should go out as the engine revs up.
Important
If this light (6) stays on, stop the engine or it may
suffer severe damage.
7) Blue light .
Comes on when right high beam is on.
fig. 3
8) Water temperature indicator .
Indicates engine coolant temperature.
Important
Stop riding if the temperature reaches the max.
value, otherwise the engine might damage.
When parking light is on, the instrument panel is lighted.
ProCarManuals.com

Ducati 998 Specifications

General

Displacement	998 cc
Bore x Stroke	100 x 63.5 mm
Compression Ratio	11.4:1
Transmission	6-speed
Frame	Tubular steel trellis
Front Brakes	2 x 320 mm discs, 4-piston calipers
Seat Height	790 mm (31.1 in)
Engine Type	L-twin, 4-valve per cylinder, Desmodromic
Power	123 hp @ 9, 750 rpm
Front Suspension	Showa 43mm upside-down fork
Rear Suspension	Showa monoshock
Rear Brakes	220 mm disc, 2-piston caliper
Fuel Capacity	17 liters
