Patient Monitor User Manual Product Specification
- 258 -
Repeatability
0.14
°C
Note 1: The accuracy consists of two parts, as following:
 Accuracy (not including sensor): ± 0.1 °C (25 °C ~ 45 °C) (monitoring mode)
 Sensor accuracy: ≤ ±0.2 °C
NOTE:
The direct mode refers to monitor mode, while adjusted mode refers to predict mode.
A.11 IBP
Complies with IEC 60601-2-34: 2011.
Technique Direct invasive measurement
Channel iM80/M80: 4 channels
iM50/iM60/iM70/M50: 2 channels
IBP
Measure
☆Measuring
Range
Art (0 to +300) mmHg
PA/PAWP (-6 to +120) mmHg
CVP/RAP/LAP/ICP (-10 to +40) mmHg
P1/P2 (-50 to +300) mmHg
Resolution 1 mmHg
☆Accuracy (not including sensor)
±
2 % or
±
1 mmHg, whichever is greater
ICP:
0 mmHg to 40 mmHg:
± 2 % or ±1
mmHg, whichever is greater;
-10 mmHg to -1 mmHg: undefined
Pressure Unit kPa, mmHg, cmH
2
O
Pressure sensor
Sensitivity 5 μV/V/mmHg
Impedance Range 300 Ω to 3000 Ω
Filter DC~ 12.5 Hz; DC~ 40 Hz
Zero
Range:
±
200 mmHg
Pressure Calibration
Range
IBP (excluding ICP) 80 mmHg to 300 mmHg
ICP 10 mmHg to 40 mmHg
Volume Displacement 7.4 x 10
4
mm
3
/100mmHg
