Emerson AMS Installation Guide

Table 8-1: Meaning of the status light (continued)
Event Status light Recommendation
Color Blinking
pattern
Health value is ≥30% and
<60% (Warning state)
Open AMS Asset Monitor
Web Interface to get
recommendations on how to
solve the issue.
Health value is <30% (Critical
state)
Red Fast flashing
(1 per 500
milliseconds)
Open AMS Asset Monitor
Web Interface to get
recommendations on how to
solve the issue.
External data point critical
(communication timeout)
Open AMS Asset Monitor
Web Interface to check the
external data point.
Device temperature critical Take appropriate measures
to reduce the environmental
temperature.
Supply voltage is out of the
OK range
OK range: 21.6 V to 26.4 V
Check the power supply.
No supply voltage --- Off Check the power supply.
1 At least one of the installed CHARMs is disabled.
8.3 Replacement and repair
In case of a defect, several components of the AMS Asset Monitor can be replaced on-site.
It is not possible to repair defective CHARMs, +24 V DC Power Modules, and AMS Asset
Monitors.
8.3.1
Replace a defective +24 V DC Power Module
In case of a defect, replace the +24 V DC Power Module.
CAUTION
Any work on the system may impair asset health monitoring and machine protection.
Prerequisites
• Spare +24 V DC Power Module
Procedure
1. Open the door of the AMS Asset Monitor.
2. Switch the power supply of the AMS Asset Monitor off.
3. Remove the defective +24 V DC Power Module.
Installation Guide Maintenance, troubleshooting, replacement and repair
MHM-97923-PBF March 2024
MHM-97923-PBF, Rev. 2.10 77

Emerson AMS Specifications

General

Output	4-20 mA, Digital
Measurement Type	Vibration, Temperature
Communication Protocol	Modbus, WirelessHART
Operating Temperature Range	-40°C to +85°C
Enclosure Rating	IP66
Power Supply	Battery, External Power
