9 Technical data
Only specifications with indicated tolerances or limit values are obligatory. Data without
tolerances or without error limits are informative data and not guaranteed. Technology is
under constant development, and specifications are subject to change without notice. If
not otherwise specified, all data refer to a nominal supply voltage of +24 V DC and an
environmental temperature of +23°C .
9.1 Connections and interfaces
Connections
Power connector
Conductor cross section
stranded minimum 0.2 mm
2
Conductor cross section
stranded maximum 2.5 mm
2
Conductor cross section AWG
minimum 24
Conductor cross section AWG
maximum12
Shield connection M6 Outside of the box
Conductor cross section
stranded minimum 0.32 mm
2
13 internal terminals for cable
shield connections
Conductor cross section
stranded maximum 2.5 mm
2
Conductor cross section AWG
minimum 22
Conductor cross section AWG
maximum 14
Interfaces
Ethernet LAN2.1 and LAN2.2
socket
2 x RJ45 shielded
Ethernet LAN2.1 and LAN2.2
data rate
10/100 Mbit/s Base TX Half and full duplex, with auto-
negotiation and Auto-MDI-X
Ethernet LAN2.1 and LAN2.2
cable length
up to 100 meter Shielded cable
Ethernet EEE supported
Ethernet LAN1 socket RJ45 shielded
Ethernet LAN1 data rate 10/100 Mbit/s / 1 Gbit/s Base T Half and full duplex, with auto-
negotiation and Auto-MDI-X
Ethernet LAN1 cable length up to 100 meters Shielded cable
SD card microSD card holder For future use
Installation Guide Technical data
MHM-97923-PBF March 2024
MHM-97923-PBF, Rev. 2.10 81

Emerson AMS Specifications

General

Output	4-20 mA, Digital
Measurement Type	Vibration, Temperature
Communication Protocol	Modbus, WirelessHART
Operating Temperature Range	-40°C to +85°C
Enclosure Rating	IP66
Power Supply	Battery, External Power
