9.2 Indications and buttons
Indications
Reset/Recovery indication light LED Blue/Green Assigned to the reset button
Front indication light LED Red/Orange/Green
Buttons
Reset/Recovery button Hidden tact switch
9.3 Slots
Internal power module +24 V DC AM 5730
Number of CHARM slots 12
Supported CHARM Terminal
Blocks
Standard Terminal Block KL4502X1-BA1
Thermocouple Terminal Block KL4502X1-NA1
Relay Terminal Block KL4502X1-MA1
Compatible CHARMS RTD KL3031X1-BA1
Thermocouple/mV KL3032X1-BA1
AI 4-20 mA (HART
1
) KL3021X1-BA1
DI 24 V DC Low Side (V DC Dry
Contact)
KL3003X1-BA1
DO 24 V DC High Side KL3002X1-BA1
VI Piezo CHARM AM 5125
VI Voltage CHARM AM 5620
VI Tach CHARM AM 5312
Address plug Plug 1 Installation requires Address
Terminal Block
1
No HART support.
9.4 Dimensions and electrical data – AMS Asset
Monitor
Electrical data
Power dissipation
<15 W Exclusive feed through power
Overvoltage category 1
