Emerson AMS Installation Guide

Table 1-3: Product type and ordering numbers of AMS Asset Monitor and compatible
DeltaV hardware
Hardware Product type number Ordering number
AMS Asset Monitor AM 5820-IM SE8701T01-IM
AMS Asset Monitor – Marine
Paint
AM 5820-IM BL SE8701T01-IM2
+24 V DC Power Module AM 5730 SE8701T02-IP
VI Piezo CHARM AM 5125 SE8701V01-PZ
VI Voltage CHARM AM 5620 SE8701V02-VT
VI Tach CHARM AM 5312 SE8701V03-TH
RTD CHARM KL3031X1-BA1 SE4303T03
Thermocouple/mV input
CHARM
KL3032X1-BA1 SE4303T02
AI 4 to 20 mA CHARM KL3021X1-BA1 SE4303T01
DI 24 V DC Low-Side Sens (dry
contact) CHARM
KL3003X1-BA1 SE4301T02
DO 24 V DC High-Side CHARM KL3002X1-BA1 SE4302T01
Standard Terminal Block KL4502X1-BA1 SE4501
Thermocouple/mV Terminal
Block
KL4502X1-NA1 SE4504
Relay Output Terminal Block KL4502X1-MA1 SE4503
Address Terminal Screw Block KL4502X1-DA1 KL4502X1-DA1
Address Terminal Plug #1 KL4501X1-BA1 KL4501X1-BA1
Channel Identifier Label\Wiring
Cover
--- SE4606T04
1.2 Symbols
Note
This symbol marks passages that contain important information.
CAUTION
This symbol marks operations that can lead to malfunctions or faulty measurements, but
will not damage the device.
DANGER
A danger indicates actions that can lead to property damage or personal injury.
According to IEC 61010, this symbol means that this device must be
operated with DC voltage.
Installation Guide General
MHM-97923-PBF March 2024
MHM-97923-PBF, Rev. 2.10 9

Emerson AMS Specifications

General

Output	4-20 mA, Digital
Measurement Type	Vibration, Temperature
Communication Protocol	Modbus, WirelessHART
Operating Temperature Range	-40°C to +85°C
Enclosure Rating	IP66
Power Supply	Battery, External Power
